    Detect Cycle in a Directed Graph

    codeanddebugBy codeanddebug3 June 2025No Comments3 Mins Read
    Share Facebook Twitter Pinterest LinkedIn Tumblr Reddit Telegram Email
    Featured Image of a question to how to detect a cycle in a directed graph
    Share
    Facebook Twitter LinkedIn Pinterest Email

    See how to solve “detect cycle in a directed graph” using depth-first search and two helper arrays. Simple idea, commented Python code, dry run, and Big-O analysis.

    What does the problem ask?

    You are given a directed graph with V vertices (0 … V-1) and a list of edges.
    Return True if the graph contains at least one directed cycle; otherwise return False. geeksforgeeks.org


    Examples

    VedgesResultWhy
    4[(0,1),(1,2),(2,0),(2,3)]True0 → 1 → 2 → 0 forms a cycle
    3[(0,1),(1,2)]FalseNo path returns to an earlier node
    1[(0,0)]TrueSelf-loop is a cycle

    Intuition & Approach

    Key idea

    While doing DFS, a back edge (an edge to a node already in the current recursion path) means a cycle.

    How we detect that

    We keep two arrays:

    • visited[] – 1 if the node has been processed completely.
    • path_visited[] – 1 if the node is in the current DFS path (the “gray” state).

    Steps:

    1. Start DFS from every unvisited node (graph may be disconnected).
    2. When we enter a node, mark both visited and path_visited.
    3. For every neighbor:
      • If neighbor is unvisited → DFS deeper.
      • If neighbor is already in path_visited → we met a gray node → cycle found.
    4. When we leave the node, clear its path_visited flag (turn it “black”).
    5. If no back edge seen in any component, the graph is acyclic.

    This is the classic “white-gray-black” DFS cycle test.


    Code

    class Solution:
        # DFS that returns True as soon as a cycle is detected
        def dfs(self, current_node, visited, path_visited, adj_list):
            visited[current_node] = 1         # mark as visited (gray → black later)
            path_visited[current_node] = 1    # mark as part of current path (gray)

            for adjNode in adj_list[current_node]:      # explore all outgoing edges
                if visited[adjNode] == 0:               # white node
                    x = self.dfs(adjNode, visited, path_visited, adj_list)
                    if x == True:                       # cycle found deeper
                        return True
                elif path_visited[adjNode] == 1:        # edge to gray node → cycle
                    return True

            path_visited[current_node] = 0    # leave path (node becomes black)
            return False

        def isCycle(self, V, edges):
            # build adjacency list
            adj_list = [[] for _ in range(V)]
            for u, v in edges:                # edge u → v
                adj_list[u].append(v)

            visited = [0] * V                 # 0 = white (not visited at all)
            path_visited = [0] * V            # 0 = not in current DFS call stack

            for i in range(V):                # handle all components
                if visited[i] == 0:
                    ans = self.dfs(i, visited, path_visited, adj_list)
                    if ans == True:
                        return True           # cycle exists
            return False                      # no cycles anywhere

    5 Code walkthrough

    1. Adjacency list quickly lists every node’s outgoing edges.
    2. dfs marks a node gray (visited=1, path_visited=1).
    3. For each neighbor:
      • If neighbor is white → recurse.
      • If neighbor is gray (path_visited=1) → back edge found → cycle.
    4. Once all neighbors are processed, node turns black (path_visited=0).
    5. Outer loop makes sure we check every disconnected part.
    6. First time True comes back, we exit early.

    6 Dry run on sample with a cycle

    V = 4, edges = [(0,1),(1,2),(2,0),(2,3)]

    Call stackvisitedpath_visitedNote
    dfs(0)[1,0,0,0][1,0,0,0]node 0 gray
    → dfs(1)[1,1,0,0][1,1,0,0]node 1 gray
    → dfs(2)[1,1,1,0][1,1,1,0]node 2 gray
    → neighbor 0 is grayback edge → return True up the stack
    Propagate True → isCycle returns True

    7 Complexity

    MeasureValue
    TimeO(V + E)
    SpaceO(V + E)

    We visit every vertex and edge once; we store the graph plus two arrays of size V.


    8 Conclusion

    Using DFS with a “currently in path” marker lets us spot a back edge—the reliable sign of a directed cycle. The method is linear, easy to code, and works for any directed graph.
