Learn how to detect cycle in a directed graph with Kahn’s algorithm. Simple intuition, commented Python code, step-by-step dry run, and clear time / space complexity.
Here’s the [Problem Link] to begin with.
What does the problem ask?
Given a directed graph with V
vertices (0 … V-1
) and a list of directed edges, tell whether the graph contains at least one cycle.
Return True
if a cycle exists; otherwise return False
.
Examples
V | edges | Output | Why |
---|---|---|---|
4 | [(0,1),(1,2),(2,0),(2,3)] | True | 0 → 1 → 2 → 0 forms a loop |
3 | [(0,1),(1,2)] | False | No edge leads back to an earlier node |
1 | [(0,0)] | True | Self-loop counts as a cycle |
Intuition & Approach
We use Kahn’s algorithm, which is really a breadth-first topological sort:
- Indegree count
For every vertex count incoming edges. Nodes with indegree 0 have no prerequisites. - Queue of ready nodes
Put all indegree-0 nodes into a queue. - Process the queue
Repeatedly pop a node, “remove” its outgoing edges by decrementing each neighbour’s indegree.
Whenever a neighbour’s indegree becomes 0, push it into the queue. - Cycle check
If we can remove (process) allV
nodes, the graph is acyclic.
If some nodes never reach indegree 0, they are locked in a cycle.
So:
- All nodes processed? → No cycle (
False
) - Some left unprocessed? → Cycle exists (
True
)
Code
from collections import deque
class Solution:
def isCycle(self, V, edges):
adj_list = [[] for _ in range(V)]
indegrees = [0 for _ in range(V)] # incoming edge counts
# Build graph and indegree array
for u, v in edges: # edge u → v
adj_list[u].append(v)
indegrees[v] += 1
queue = deque()
result = [] # list of processed nodes
# Put all sources (indegree 0) into the queue
for i in range(V):
if indegrees[i] == 0:
queue.append(i)
# Standard BFS over the DAG / graph
while len(queue) != 0:
current_node = queue.popleft()
result.append(current_node)
for adjNode in adj_list[current_node]:
indegrees[adjNode] -= 1 # remove edge current → adjNode
if indegrees[adjNode] == 0: # neighbour becomes a new source
queue.append(adjNode)
# If we processed every vertex, no cycle; otherwise a cycle exists
if len(result) == V:
return False # acyclic
return True # cycle present
Code walkthrough
- Graph build –
adj_list[u]
stores outgoing edges;indegrees[v]
counts incoming edges. - Initial queue – all nodes with indegree 0 have no dependencies, so they can be deleted first.
- BFS loop – for each popped node we “delete” its edges by lowering neighbours’ indegrees.
- Cycle decision –
- If
result
length equalsV
, every node was deletable → no cycle. - Otherwise at least one node stayed stuck with positive indegree, proving a cycle.
- If
Dry run on the first example
V = 4
, edges = [(0,1),(1,2),(2,0),(2,3)]
Step | Queue | result | Key indegree changes |
---|---|---|---|
Build | – | – | indeg = [1,1,1,1] |
No node has indegree 0 | [] | [] | queue empty from start |
BFS ends immediately | [] | [] | processed = 0 |
processed ≠ V (0 ≠ 4) → cycle |
Algorithm returns True.
Complexity
Measure | Value |
---|---|
Time | O(V + E) |
Space | O(V + E) |
Conclusion
Kahn’s algorithm offers a neat BFS way to detect cycles in directed graphs:
- Keep indegrees.
- Remove zero-indegree nodes layer by layer.
- If anything remains, a cycle must be blocking progress.
The method is linear, easy to code, and widely used in scheduling and dependency resolution tasks.
