Need not just distances but the real route? Learn how to extend Dijkstra’s algorithm to reconstruct the shortest path from node 1 to node n. We break down the idea, annotate the Python code, walk through the sample graph [1-4-3-5]
, and cover complexity.
Here’s the [Problem Link] to begin with.
1. What are we doing?
- Input –
n
: number of vertices (1-indexed)edges
: undirected weighted edges[u, v, w]
- Goal –
- Use Dijkstra to find the minimum-cost path from vertex
1
to vertexn
. - Return the list of nodes in order; if
n
is unreachable, return[-1]
.
- Use Dijkstra to find the minimum-cost path from vertex
2. Quick example
n = 5
edges = [
[1,2,2], [2,5,5],
[2,3,4], [1,4,1],
[4,3,3], [3,5,1]
]
Shortest path from 1
to 5
is
1 → 4 → 3 → 5
(1) (3) (1) total = 5
print(shortest_path(...))
outputs
[1, 4, 3, 5]
3. Intuition & approach
3.1 Plain Dijkstra recap
- Keep a min-heap of
(distance, node)
. - Pop the lightest node, relax its edges; distances only improve.
3.2 How to retrieve the actual path
- For every relaxation that really improves
distance[v]
, store the predecessor: pythonCopyEditparent[v] = u
- After the algorithm ends,
parent[x]
tells you the previous vertex on the shortest route tox
. - To reconstruct the path to
n
:- Start at
n
, push it onto a list. - Follow
parent
pointers backwards until you reach1
. - Reverse the list.
- Start at
If distance[n]
stayed at ∞
, vertex n
is unreachable—return [-1]
.
4. Code
import heapq
import sys
def shortest_path(n, m, edges):
# 1. Build undirected adjacency list
adj_list = [[] for _ in range(n + 1)]
for u, v, wt in edges:
adj_list[u].append([v, wt])
adj_list[v].append([u, wt])
# 2. Dijkstra initialisation
distance = [sys.maxsize] * (n + 1)
distance[1] = 0 # source vertex
parent = [i for i in range(n + 1)] # parent[i] = predecessor of i
pq = [] # min-heap of (dist, node)
heapq.heappush(pq, (0, 1))
# 3. Main loop
while pq:
dist, node = heapq.heappop(pq)
if dist != distance[node]: # ignore stale heap entries
continue
for adjNode, wt in adj_list[node]:
new_dist = dist + wt
if new_dist < distance[adjNode]: # relaxation succeeds
distance[adjNode] = new_dist
heapq.heappush(pq, (new_dist, adjNode))
parent[adjNode] = node # record the path
# 4. Reconstruct path or report unreachable
if distance[n] == sys.maxsize:
return [-1]
path = []
node = n
while parent[node] != node: # follow parents back to 1
path.append(node)
node = parent[node]
path.append(1)
path.reverse()
return path
# ----- demo run -----
n = 5
m = 6
edges = [
[1, 2, 2], [2, 5, 5],
[2, 3, 4], [1, 4, 1],
[4, 3, 3], [3, 5, 1]
]
print(shortest_path(n, m, edges)) # ➜ [1, 4, 3, 5]
5. Dry run on the sample graph
Pop from heap | Relaxations (better distance found?) | parent updates |
---|---|---|
(0,1) | 1→2=2 ✔ , 1→4=1 ✔ | parent[2]=1 , parent[4]=1 |
(1,4) | 4→3=4 ✔ | parent[3]=4 |
(2,2) | 2→3=6 ✖ , 2→5=7 ✔ | parent[5]=2 |
(4,3) | 3→5=5 ✔ better than 7 | parent[5]=3 |
(5,5) | – | – |
Backward chain 5 ← 3 ← 4 ← 1
reversed ⇒ [1,4,3,5]
.
6. Complexity
Metric | Cost | Notes |
---|---|---|
Time | O((n + m) log n) | Standard heap-based Dijkstra. |
Space | O(n + m) | Adjacency list + distance + parent + heap. |
7. Key takeaways
- Path reconstruction needs only one extra
parent
array. - Always update
parent[v]
only when you genuinely shortendistance[v]
. - For undirected graphs, remember to insert edges both ways in
adj_list
. - Make sure to skip stale heap entries (
dist != distance[node]
) for efficiency.
Armed with this pattern you can extract not just the cost but the exact sequence of nodes for any shortest-path query with Dijkstra’s algorithm.
