Learn how to perform topological sorting of a DAG using Kahn’s algorithm (BFS based). Clear steps, commented Python code, dry-run example, and Big-O complexity.
Here’s the [Problem Link] to begin with.
What does the problem ask?
Given a directed acyclic graph (DAG) with V
vertices (0 … V-1
) and a list of directed edges, return any order of the vertices such that for every edge u → v
, vertex u
appears before v
in the list.
Example
V = 6
Edges = [
(5, 0), (5, 2),
(4, 0), (4, 1),
(2, 3), (3, 1)
]
A correct topological order is 5 4 2 3 1 0
.
(Other valid orders are possible.)
Intuition & Approach
Kahn’s algorithm (BFS idea)
- Indegree
For every vertex count how many incoming edges it has.
Vertices with indegree 0 have no prerequisites; they can start the order. - Queue of ready vertices
Put all indegree-0 vertices in a queue. - Process the queue
- Pop a vertex, add it to the answer list.
- For each outgoing edge
u → v
, reducev
’s indegree by 1. - If
v
’s indegree becomes 0, pushv
into the queue.
- Repeat until the queue is empty.
If we outputV
vertices, we have a valid topological order.
(If fewer—this would mean the graph had a cycle, but the problem guarantees a DAG.)
Code
from collections import deque
class Solution:
def topoSort(self, V, edges):
adj_list = [[] for _ in range(V)] # adjacency list
indegrees = [0 for _ in range(V)] # incoming edge counts
# build graph and indegree array
for u, v in edges: # edge u → v
adj_list[u].append(v)
indegrees[v] += 1
queue = deque() # vertices ready to be processed
result = [] # final topological order
# add all starting points (indegree == 0)
for i in range(V):
if indegrees[i] == 0:
queue.append(i)
# BFS over the DAG
while queue:
current_node = queue.popleft()
result.append(current_node)
# remove current_node’s edges
for adjNode in adj_list[current_node]:
indegrees[adjNode] -= 1
if indegrees[adjNode] == 0: # new node becomes ready
queue.append(adjNode)
return result # contains V vertices in order
Code walkthrough
- Build
adj_list[u]
holds all vertices reachable fromu
.indegrees[v]
counts how many edges come intov
.
- Initial queue
All vertices with no incoming edges can be placed first in the order. - Loop
- Take the next ready vertex.
- Add it to
result
. - “Delete” its outgoing edges by lowering each neighbor’s indegree.
- When a neighbor’s indegree hits 0, push it onto the queue.
- Finish
When the queue is empty,result
has one valid topological order.
Dry run on the sample graph
Step | Queue | Result | indegrees (key changes) |
---|---|---|---|
Start | [4, 5] | [] | 4→0,5→0 |
Pop 4 | [5] | [4] | 0→1,1→1 |
Process edges 4→0, 4→1 | [5] (no new zeros) | ||
Pop 5 | [] | [4,5] | 0→0,2→1 |
Edge 5→0 lowers indegree(0) to 0 → queue [0] | |||
Edge 5→2 lowers indegree(2) to 0 → queue [0,2] | |||
Pop 0 | [2] | [4,5,0] | (0 has no children) |
Pop 2 | [] | [4,5,0,2] | 3→0 → queue [3] |
Pop 3 | [] | [4,5,0,2,3] | 1→0 → queue [1] |
Pop 1 | [] | [4,5,0,2,3,1] | done |
Final order: 4 5 0 2 3 1
—valid.
Complexity
Measure | Value |
---|---|
Time | O(V + E) |
Space | O(V + E) |
We look at each vertex and each edge once. We store the adjacency list (E
) and two arrays of size V
.
Conclusion
Kahn’s algorithm uses a simple queue and indegree counts to produce a topological order with breadth-first style processing. It is intuitive, runs in linear time, and is often the first choice for scheduling tasks with dependencies.
